NTLMv2 authentication deep dive IBM

NTLMv2 authentication with IBM Unica Marketing Platform

IBM Marketing Platform supports multiple authentication mechanisms. Microsoft Windows Integrated login (NTLM v1) is one such mechanism that is widely deployed especially in conjunction with the Microsoft Windows 2003 Active Directory services. With the arrival of Microsoft Windows 2008 Server and Microsoft Windows 7 the default minimum standard (LmCompatibilityLevel) has changed and requires usage of NTLM v2 protocol. NTLM v2 is the successor to NTLM v1 with enhanced security. NTLM v2 is not natively supported by IBM Marketing Platform. The purpose of this article is to outline a solution using Microsoft Internet Information Services (a component of the Windows 2008 Server OS) that gets NTLM v2 working with the IBM Cross Channel Marketing suite and is compatible with the already released application versions.

This article is written by Abdul Rahim Suriya who works as Software Engineer for IBM Software Labs for IBM Cross Channel Marketing products (formerly Unica).

Target Audience

  • Administrators at the customer site using Windows integrated login and considering upgrade to Windows 2008 servers
  • Consultants and Services team members performing a deployment to support NTLM v2
  • Tech Support team members supporting Platform deployments working with NTLM v2

1. Introduction

Integrated Windows Authentication refers to the Microsoft devised authentication mechanism that does not prompt users for the username and password. It involves cryptographic exchange between a user agent (browser) and the Active Directory aware applications (IIS for example) to ensure the user agent is a valid AD domain user. IWA is typically deployed in an intranet environment. IWA can be performed using underlying authentication protocols like NTLM, Kerberos.

IBM Marketing Platform supports windows integrated login as an authentication mechanism utilizing NTLM v1 as the authentication protocol in conjunction with Internet Explorer and Windows Active Directory. The default LmCompatibilityLevel setting for the newer server OS (Windows Server 2008, Windows Server 2008 R2, Windows Server 2012) and the new clients (Windows 7) requires the NTLM v2 authentication protocol to be the default authentication protocol.

The remainder of this article describes how you can use NTLM v2 for the IBM Cross Channel Marketing suite with some help from the Microsoft Internet Information Services web server.

2. Solution Concept

IBM Marketing Platform supports a windows integrated login mechanism that enables sign in from Internet Explorer that can negotiate the NTLM v1 headers. The native support for the NTLM protocol is limited to NTLM v1 in IBM Marketing Platform. A basic deployment of IBM Marketing Platform with windows integrated login is depicted in Fig 1

Basic deployment of Platform with Windows Integrated Login

Figure 1- Basic Deployment of Marketing Platform with Windows integrated login

To support NTLM v2, the basic deployment outlined in Fig 2 is proposed

IBM Marketing Platform deployed with web server supporting NTLMv2

Figure 2- Marketing Platform deployed with web server supporting NTLMv2

For Windows Integrated Login using NTLM V2, IBM Marketing Platform leverages another supported authentication mechanism – web access control. The web access control mechanism enables user authentication to occur outside the suite and expects the authenticated user information to be supplied to IBM Marketing Platform in the form of a configurable HTTP(s) request header.

This mechanism is typically used in conjunction with the IBM Tivoli Access Manager or CA SiteMinder. These access control mechanisms authenticate the users and set a request header which is then made available to the backend web application server (WebSphere or WebLogic) and is consumed by IBM Marketing Platform. For NTLMv2 we will use Internet Information server (Microsoft IIS) which understands and supports NTLM v2 natively. The authentication is carried out by IIS using the request header along with Web access control. This mechanism conveys the logged-in user information is conveyed to Marketing Platform.

3. Additional Components required

This solution requires intermediate components that can handle the authentication using NTLM v2 and pass on the logged-in user information to IBM Marketing Platform.

The following third party components are required for this solution (as compared to an IBM Marketing Platform installation that works with NTLM v1):

  • Microsoft Internet Information Services (IIS). To enable communication between IIS and our Application server you will need Application server plug-in for Microsoft IIS – ensure the correct plug-ins are selected for the your OS and Application Server version combination
  • URL re-writer that has access to authentication information – you can ISAPI Rewrite Lite Edition, a free component. NOTE: Microsoft provides a URL Rewriter module for IIS. However that module will not work for this solution due to the architecture – the module is invoked before the authentication has happened and hence the URL Rewrite module does not have access to the authentication information. This necessitates usage of an ISAPI Filter for IIS that has access to the authentication information and can pass it on to the backend as a HTTP request header

3.1 Microsoft Internet Information Services (IIS)

The following instructions apply to Microsoft IIS 7 or later

  1. Ensure IIS is installed on a system that has the same network domain suffix (unicaindia.com in examples below) as the IBM Marketing Platform application server host.
  2. For WebSphere + IIS combination, enable the IIS Role Services for IIS 6 Management compatibility components as outlined in the WebSphere IIS plugin documentation
  3. Ensure Windows Integrated authentication is allowed on IIS. For more details – refer (A)
  4. Disable anonymous access for your web site and then enable Windows authentication (you might want to do this step after a confirmation that the web server is able to correctly pass on the requests to backend application server)
  5. If using 32-bit plug-ins on 64-bit OS, Enable 32-bit application support within IIS. Refer (C)

3.2 IIS URL Re-writing for setting a request header

The request header should be set for the application server to determine the authenticated user.

Use ISAPI Rewrite (Lite Edition) or another compatible IIS URL re-writer. Refer (B).

  • Download the ISAPI_Rewrite filter from isapirewrite.com – the freeware lite edition is sufficient for this solution
  • Install the ISAPI_Rewrite filter
  • Configure the rewrite filter (httpd.conf) with the following rewrite rules (sample)

RewriteEngine on

RewriteCond %{REMOTE_USER} UNICAINDIA\\(.*)

RewriteHeader unicasso: .* %1

The above rewrite rule extracts the authenticated user name from the REMOTE_USER variable value and strips the domain name with trailing backslash (“UNICAINDIA\” in this case) before setting the remaining text as a new request header with the name unicasso

ISAPI Rewrite configuration

Figure 3- ISAPI Rewrite configuration

  • Ensure that in the ordered list of ISAPI filters for the website, the URL rewriter appears before the application server specific ISAPI filter.

3.3 Application Server plug-in for Microsoft Internet Information Services

The application server plug-in for IIS is required to proxy the HTTP(s) request from IIS to the backend application server.

For WebLogic, the IIS plug-in is supplied as a DLL file named iisproxy.dll and can be found under the WL_HOME/server/plugin/win/ folder. Refer the Oracle WebLogic documentation for further information.

For WebSphere, the IIS plug-in is part of a separate installation package (refer the technote http://www-01.ibm.com/support/docview.wss?rs=899&uid=swg21367202) to be additionally installed on the server hosting the IIS.

4. Detailed Instructions for WebLogic (WL 11gR1+ – Refer (D))

1.    Open IIS Manager from the control panel

2.    Create a new site (example: UMP) and assign a port to it
A new site defined in IIS
Figure 4- A new site defined in IIS

3.    Create a folder under IIS for the site (at the same level as wwwroot) under inetpub

4.    Copy the file iisproxy.dll and iisforward.dll from server\plugin\win\64 folder of the Application server installation to the folder created in step (3).

The Site folder on the file system containing WebLogic Application Server IIS plugin

Figure 5- The Site folder on the file system containing WebLogic Application Server IIS plugin

5.    If you are using the 32 bit DLL on a 64-bt OS, enable 32-bit application support at the site level as follows

  • Open IIS7.x and click on Application Pools.
  • Right-click on the application pool for your website or the default application pool and go to the Advanced Settings tab.
  • Ensure that Enable 32-bit applications is set to True

6.    Select your application name and add ISAPI filter as follows-

  • filter name: WL_IIS_FORWARD
  • executable: <path to the iisforward.dll>

WL IIS Forward ISAPI filter
Figure 6- WL IIS Forward ISAPI filter

7.    Click on Handler mapping at the application level. Add a script map with the following details

  • Name: WL_IIS_PROXY
  • Request Path: *
  • Executable: <File system path to iisproxy.dll>

IIS Proxy handler mapping
Figure 7- IIS Proxy handler mapping

8.    Create an iisproxy.ini file that will tell the WebLogic ISAPI filter about the location of the weblogic server (host, port) and the paths that should be forwarded to WebLogic instance
<sample content for iisproxy.ini>
WebLogicHost=wlserver.unicaindia.com
WebLogicPort=8500
WlForwardPath=/weblogic
PathTrim=/weblogic

9.    Restart the IIS server and WebLogic server instance.
10.    The URL for IIS host and site port should be followed by /weblogic/unica, the WebLogic IIS proxy would handle the trimming of the /weblogicfrom the request path (Refer the value of PathTrim from step 8 above). In case you want to change the access URL, adjust the PathTrim value and the access URL accordingly.

5. Detailed Instructions for WebSphere (Refer (E))

1.  Install the WebSphere web-server plug-ins including the latest fix pack. Use a path that does not include parenthesis. Ensure that the version number of the web server plug-in and the application server are compatible, Refer (F). Examples in this article use WebSphere Application Server 7.0.0.19 and 8.0.0.2 with their associated plug-ins

2.  On the WAS instance, update the virtual host setting to include the port number for the IIS web site you will be using.  Failure to do this step results in 404 errors when accessing the application via IIS.

Adding the IIS port to the Virtual host (default_host)

Figure 8- Adding the IIS port to the Virtual host (default_host)

3. For WebSphere Application Server 8.x

  • Define a web server of the type IIS on the WebSphere instance and set the plug-in properties as required for your environment
  • Generate and Propagate the web-server plug-in. No changes should be required to the generated web-server plug-in. However, you might want to increase the ESI cache size or disable ESI altogether.

For detailed instructions refer to the IBM Websphere plugins documentation

4.  For WebSphere Application Server 7.x

  • Execute <Plugins Home>\bin\configurewebserver1.bat passing in the parameter -profileName <WAS_PROFILE_NAME> this will define a web server of the type IIS on the WebSphere instance.
  • plugin-cfg.xml file will be generated in <Plugin_Home>\config\webserver1 location. Generate and Propagate the web-server plug-in. Save the necessary changes.
  • To configure IIS7 Plugin with WAS, navigate to the <Plugins Home>\bin path and execute configureIIS7Plugin.bat.e.g.  configureIIS7Plugin.bat -plugin.home C:\IBM\Plugins -plugin.config.xml  C:\IBM\Plugins\config\webserver1\plugin-cfg.xml For detailed instructions kindly refer the IBM Websphere plugins documentation

5.  On the IIS web site, create a site (example: Unica). Add a virtual directory to the web site. Name the alias “sePlugins”. The corresponding physical path for this virtual directory is the folder containing the iisWASPlugin_http.dll.

  • Click the Test Settings button. If the settings test fails, then either change the permissions of the physical directory, or select Connect As, and let IIS connect as a Windows user account that has authority to files in that physical path.

NOTE: Even if you add a virtual directory the URL patterns will not change.

Virtual directory defined for IIS site

Figure 9- Virtual directory defined for IIS site

Physical folder contents corresponding to the sePlugins virtual directory

Figure 10- Physical folder contents corresponding to the sePlugins virtual directory

6.  In the navigation tree, select the sePlugins virtual directory that you just created. On the Features panel, double-click Handler Mappings, and then click Edit Feature Permissions on the Actions panel. Select Script and Execute, if they are not already selected. Click OK

Edit Feature Permissions

Figure 11- Edit Feature permissions

7.  Within the same folder as iisWASPlugin_http.dll, edit the plugin-cfg.loc file (add the file if it does not exist) to contain 2 lines – the complete file system location of the plugin-cfg.xml file on line # 1 and a blank line # 2

8.  At the web site level, add an ISAPI filter with a name like iisWASPlugin and select the iisWASPlugin_http.dll as the executable

ISAPI filter for the WAS IIS plug-in

Figure 12- ISAPI filter for the WAS IIS plug-in

9.  At the top (server) level node in IIS manager, use the “ISAPI and CGI Restrictions” features panel item to add a new restriction entry with a description like “WASPlugin”, the location of the iisWASPlugin_http.dll in the “ISAPI or CGI Path” and select the checkbox against the “Allow extension path to execute”

ISAPI and CGI restriction setting for WAS IIS plug-in

Figure 13- ISAPI and CGI restriction setting for WAS IIS plug-in

10.  Restart IIS server and your WebSphere Application Server profile.

11.  If you cannot get the solution working as desired, changing the log level in the plugin-cfg.xml from ERROR to INFO or DEBUG and accessing the IIS URL from Internet Explorer may help. Check the following points

  • The URI pattern defined in the plugin-cfg.xml should have /unica/* as one of the entries
  • The transport hostname should point to the host machine where Platform web application is running
  • The Virtual host settings should include the IIS site port number on which the plug-in is configured

6. Marketing Platform Settings

1.  Configure the LDAP server details (AD 2008+) in Marketing Platform and synchronize users. For more details refer to the IBM Marketing Platform Administrator’s Guide.

2.  Change the setting for “Web access control header variable”  to use the variable name as specified in the re-write rules (example: unicasso in the example used in this document)

Configure Web Access Control for IBM Marketing Platform

Figure 14- Configure Web Access Control for IBM Marketing Platform

3.  Update the login mode of platform to “Web Access Control”

4.  Ensure that the navigation URL (IBM Marketing Platform URL) specified is the IIS site URL and restart the web application

Update the IBM Marketing Platform navigation URL as appropriate

Figure 15- Update the IBM Marketing Platform navigation URL as appropriate

5.  When using this solution along-with dashboard.war, users might notice issue with access to the dashboard (NullPointerException is displayed instead of the dashboard contents). A fix for this issue is targeted for release in 8.2.0.7 and 8.5.0.4

7. Important Points

  • Any web server that supports the NTLMv2 authentication mechanism and is able to communicate with the backend application server should work for the proposed solution
  • Irrespective of Windows Integrated Login – Windows 2008 (R2) Server AD can still be used as a source of LDAP login with Marketing Platform without requiring any change in the setup. The end users can login using their domain username and password.
  • Microsoft provides a URL Rewriter module for IIS. However that module will not work for this solution due to the architecture – the module is invoked before the authentication has happened and hence the URL Rewrite module does not have access to the authentication information. This necessitates usage of an ISAPI Filter for IIS that has access to the authentication information and can pass it on to the backend as a HTTP request header.
  • For any IIS related problems/queries contact your system/network administrator

8. References

A. Windows Authentication with Microsoft IIS – http://www.iis.net/ConfigReference/system.webServer/security/authentication/windowsAuthentication

B. ISAPI Rewrite module – http://www.isapirewrite.com/

C. Issue when Enable 32-bit application is not set – http://helpdeskgeek.com/how-to/calling-loadlibraryex-on-isapi-filter/

D. Installing and Configuring Microsoft IIS plugin with WebLogic – http://docs.oracle.com/cd/E12840_01/wls/docs103/plugins/isapi.html

E. Configure WAS web server plug-in for the best results – http://www-01.ibm.com/support/docview.wss?uid=swg21450051&acss=dakc

F. IBM web server plug-in policy for Websphere Application Server – https://www-304.ibm.com/support/docview.wss?uid=swg21160581

G. Application Request Routing module for Microsoft IIS – http://www.iis.net/download/ApplicationRequestRouting

Vote of THANKS — This a copy paste from IBM website. Keeping it for my perosnal reference. Posted AS IS.

Managed service account password sync issue

You create a managed service account in a domain.
•You install the managed service account on a computer that is running Windows 7 or Windows Server 2008 R2.
•You configure a service to use the managed service account on the computer.

This issue occurs because the Kerberos and NTLM security providers are not notified when the password of the managed service account is changed.

http://support.microsoft.com/kb/2494158

Nice tool to find and replace texts with in huge number of files

I came across a free tool which is so good and easy to use. It really reduces a huge effort of find and replace some particular word with in huge number of files. This is very small in size file and it is great.

Thanks to digitalvolcano who gives the software free.

http://www.digitalvolcano.co.uk/tcdownloads.html

Run ESX 4.0 on Vmware workstation with less than 2 GB RAM

ESX:

  1. Install vSphere(ESX) with at least 2 GB memory
  2. Login to the Service Console and type the following:
    vi /etc/vmware/init/init.d/00.vmnix
  3. Change the following line to the desired value:
    RequiredMemory=2064384
  4. Shutdown the virtual machine and change the VMs memory and boot it up!

Thanks Mark for the comment on ESXi:

  1. Install vSphere(ESXi) with at least 2 GB memory
  2. Login to the console via the “unsupported” method.
  3. Edit the file /etc/vmware/esx.conf and add the following line:
    /vmkernel/minMemoryCheck = “false”
  4. Save the file and shutdown ESXi, change the memory and boot it up!

Source: -Yellow-Bricks

Customize Places Bar when you open Save As option in Windows 7

I found one more nice article for adding a folder to the Places Bar in windows 7. It works great and it is a nice explanation

Thanks to the author. I am copy pasting it to keep it for my reference.

The source link:-http://www.howtogeek.com/97824/how-to-customize-the-file-opensave-dialog-box-in-windows/

How to Customize the File Open/Save Dialog Box in Windows

00_customized_places_bar

Generally, there are two kinds of Open/Save dialog boxes in Windows. One kind looks like Windows Explorer, with the tree on the left containing Favorites, Libraries, Computer, etc. The other kind contains a vertical toolbar, called the Places Bar.

The Windows Explorer-style Open/Save dialog box can be customized by adding your own folders to the Favorites list. You can, then, click the arrows to the left of the main items, except the Favorites, to collapse them, leaving only the list of default and custom Favorites.

The Places Bar is located along the left side of the File Open/Save dialog box and contains buttons providing access to frequently-used folders. The default buttons on the Places Bar are links to Recent Places, Desktop, Libraries, Computer, and Network. However, you change these links to be links to custom folders of your choice.

We will show you how to customize the Places Bar using the registry and using a free tool in case you are not comfortable making changes in the registry.

Using the Registry

To open the Registry Editor, open the Start menu and enter “regedit.exe” in the Search box. Click the regedit.exe link in the results or press Enter.

If the User Account Control dialog box displays, click Yes to continue.

NOTE: You may not see this dialog box, depending on your User Account Control settings.

Navigate to the following key:

HKEY_CURRENT_USER \ Software \ Microsoft \ Windows \ CurrentVersion \ Policies \ comdlg32 \ Placesbar

The comdlg32 and Placesbar keys may not exist. If not, you need to create them. For example, to create the comdlg32 key, right-click the Policies key and select New | Key.

A new key is created and the text is highlighted. Rename the new key “comdlg32.”

Add Placesbar as a new key under the comdlg32 key.

Select the Placesbar key and right-click in the right pane. Select New | String Value from the popup menu.

Rename the new value Place0. You can create up to 5 entries: Place0, Place1, Place2, Place3, Place4. You don’t have to define all five places, but they must be defined in numerical order.

To define the target folder for a PlaceX value, double-click on the value name.

In the Value data edit box on the Edit String dialog box, enter the full path for the location you want to add to the Places Bar and click OK.

You can also define a target folder using a numerical value for system folders. There is a table below listing the numerical values for the different system folders. To define a target folder using a numerical value, create a new DWORD (32-bit) Value the same way you created the String Value.

Double-click on the new DWORD value.

Enter a numerical value in the Value data edit box. Use the values from the table below the image.

The following “DWORD” values can be used to add standard folders to the Places Bar.

00 – Desktop
01 – Internet Explorer
02 – Start Menu\Programs
03 – My Computer\Control Panel
04 – My Computer\Printers
05 – My Documents
06 – Favorites
07 – Start Menu\Programs\Startup
08 – \Recent
09 – \SendTo
0a – \Recycle Bin
0b – \Start Menu
0c – – logical “My Documents” desktop icon
0d – My Music
0e – My Videos
10 – \Desktop
11 – My Computer
12 – My Network Places
13 – \NetHood
14 – WINDOWS\Fonts
15 – Templates
16 – All Users\Start Menu
17 – All Users\Programs
18 – All Users\Start Menu
19 – All Users\Desktop
1a – \Application Data
1b – \PrintHood
1c – \Local Settings\Application Data
1d – – Nonlocalized startup
1e – – Nonlocalized common startup
1f – Favorites
20 – Temporary Internet Files
21 – Cookies
22 – History
23 – All Users\Application Data
24 – WINDOWS directory
25 – System32 directory
26 – Program files
27 – My Pictures
28 – USERPROFILE
29 – – x86 system directory on RISC
2a – – x86 C:\Program Files on RISC
2b – C:\Program Files\Common
2c – – x86 Program Files\Common on RISC
2d – All Users\Templates
2e – All Users\Documents
2f – All Users\Start Menu\Programs\Administrative Tools
30 – – \Start Menu\Programs\Administrative Tools
31 – Network and Dial-up Connections
35 – All Users\My Music
36 – All Users\My Pictures
37 – All Users\My Video
38 – Resource Directory
39 – Localized Resource Directory
3a – Links to All Users OEM specific apps
3b – USERPROFILE\Local Settings\Application Data\Microsoft\CD Burning

Select Exit from the File menu to close the Registry Editor.

The Places Bar on the Save dialog box displays the custom folders and chosen system folders.

Using PlacesBar Editor

For those of you who don’t feel comfortable making changes to the registry or who just want an easier way to customize the Places Bar, there is a free tool available called PlacesBar Editor. Download the tool using the link at the end of this article and follow the instructions to install it. If the User Account Control dialog box displays during installation, click Yes to continue.

NOTE: You may not see the User Account Control dialog box, depending on your User Account Control settings.

Use the shortcut created on the desktop to run PlacesBar Editor. You may see the User Account Control dialog box again.

The first time you run PlacesBar Editor, the following dialog box displays, encouraging you to donate. Your default web browser also opens to a PayPal page, suggesting a donation.

The main interface displays showing a toolbar and two tabs. The Windows tab allows you to make changes to File Open and File Save dialog boxes containing the Places Bar. To define a custom target folder for one of the places, select the Custom check box for that place. Click the folder button to the right of the User Folders edit box to select a folder, or type in the full path to a folder. To select a system folder for a place, select a folder from the drop-down list under System Folders for that place.

As mentioned at the beginning of this article, some programs use the Windows Explorer-like File Open and File Save dialog box. Microsoft Office programs (and some other Microsoft programs, like Notepad and Paint) use this style of dialog box.

You can use PlacesBar Editor to customize the Microsoft Office dialog boxes as well. Click the Office tab. For each custom folder you want to add, enter a name for the folder in the edit box under Folder Name. Use the folder button to select the desired folder or enter the full path to the desired folder in the edit box under User Folders. You can add up to five additional custom folders. These folders are added to the Favorites, and also display as Favorites in Windows Explorer.

To apply changes for each tab, you must click Save when that tab is active. To apply changes for Office programs, make sure the Office tab is active and click Save. To save changes you made on the Windows tab, you must click the Windows tab and click Save again.

A dialog box displays telling you that the changes were made successfully.

Once you apply, or save, your changes, on a tab, you can test those changes by clicking the Test button.

The appropriate dialog box for the currently selected tab displays. If the Office tab is active, an Office program like Word or Excel opens and the Open dialog box displays. Click Cancel on the Open dialog box to close the dialog box and the program.

You can revert back to the default settings for both types of File Open and File Save dialog boxes by clicking the Defaults button. You must click the Defaults button for each tab separately.

A Confirm dialog box displays. Click Yes if you’re sure you want to revert to the defaults.

To close PlacesBar Editor, click Exit.

Customizing the File Open and File Save dialog boxes with custom folders can improve your productivity, especially if the folders you use most often are several layers deep in your folder structure.

Download PlacesBar Editor from http://melloware.com/download/.

Vmware Nice KB articles

Few KB articles which I went through and feel very useful and great.

Keeping this for my Future reference.

Recreating a missing virtual machine disk (VMDK) descriptor file
http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=1002511

Unmounting a LUN or Detaching a Datastore/Storage Device from multiple ESXi 5.x hosts
http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2004605

Investigating virtual machine file locks on ESXi/ESX
http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=10051

Methods of upgrading to ESXi 5.1
http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2032757

Upgrading to vCenter Server 5.1 best practices
http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2021193

Installing or upgrading to ESXi 5.1 best practices
http://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2032756

Find WWN Number for Windows servers for EMC

EMC has got a nice tool to find the WWN numbers of the HBA for windows servers.

Download the INQ tool from emc site ftp://ftp.emc.com/pub/symm3000/inquiry/

Select the higher version folder.<as of now v7.5.0.0/

Then select the download according to your windows version (32 bit or 64 bit)

inq.windowsamd64 – 64 bit
inq.winia – 32 bit

Copy it to folder in C:\inq

from command prompt run the command as follows

c:\inq\inq.windowsamd64 -hba

This will give all details about the HBA cards.
